MTL 725 Programmable Alarm Annunciators
With a range of three window sizes and six LED colors, a configuration and size will be available to match your exact requirements. Each individual alarm way is fully programmable from the front, using the integral programming module. This allows for many thousands of possible combinations.
Numerous relay outputs are included as standard to connect to external equipment and individual repeat relays can be supplied as an option. The ASIC technology utilised in this design has a proven track record in a wide range of industries around the world
MTL 725 Programmable Alarm Annunciators
Efficiency
Fully programmable from front
Reliability
Fewer components for high reliability
Ease of Use
Ultra-bright LEDs in 6 colors
Certifications and Compliances
CE Marked:
Designed to meet the requirements of European EMC and LVD Directives
Compliance:
Emissions: BS EN 61000-6-4:2007+ A1:2011
Immunity: BS EN 61000-6-2:2005
LVD: BS EN 61010-1:2010 and IEC61010-2-201
Surge Immunity:
ANSI/IEEE C37.90.1:1989, BS EN 61000-4-5:2006
Environment
Operating temperature: -20ºC to 60ºC
Humidity: 0–95% RH, non-condensing
Protection
Front of panel: IP41
Rear of enclosure: IP20
Optional covers and enclosures to provide IP54 up to IP67 protection
Design Features
Only 145 mm deep
Modular construction from 1 to 256 alarm channels
Multi-redundant design so there is no single point of failure
Choice of window sizes
Available in six colors with conventional filament lamps or removable LED assemblies
Each channel programmable from the front
Low cost RS485 bi-directional communications option
Panel or 19” rack mounting or fully integrated into wall mounting or floor standing enclosures
Proven, ASIC-based technology: fewer components means higher reliability
About Eaton MTL Instruments
Eaton MTL Instruments, a division of Eaton Corporation (USA), is a global leader in surge protection solutions for signal, data and power applications. With over 50 years of experience, MTL products are engineered to perform reliably in harsh and hazardous environments.
Viet Thang Loi Technology Company Limited is the authorized distributor of Eaton MTL Instruments (MTL) and Eaton Crouse-Hinds (CEAG) in Vietnam. Please contact us for more details.
More detail
To specify the correct MTL 725 configuration for your application, please refer to the following options:
Configuration Parameter | Available Options |
|---|---|
Number of Alarm Ways | Customizable from 2 to 256 ways using modular matrix assembly. |
Window Dimensions |
|
LED Colors | Red, Amber, Yellow, White, Green, Blue. |
Supply Voltage | Standard 24VDC, 48VDC, or AC power supplies. |
Alarm Sequences | Field-programmable sequences to ISA S18.1 (Sequences A, M, R, F1, F2...). |
Communication Port | Optional Modbus RS485 for integration with SCADA/DCS systems. |
