Certifications and compliances

For a complete listing of certifications and approvals across the MTL Redundant Fieldbus Power Supply range, please download the relevant product datasheets from the Resources section of this product family page.

Design features

Eaton offers three flexible solutions for redundant fieldbus power supplies:

MTL 9180 Range – N+1 Redundant Fieldbus Power Supplies

The MTL 9180 range is recommended for all new applications. Its unique N+1 redundancy architecture provides maximum flexibility for system designers, allowing initial project requirements to be met using two power supply modules per segment, with the option to add a third module later as system expansion demands increase.

This approach typically delivers up to 25% savings in initial capital cost compared with conventional 1+1 redundant architectures. High system availability is achieved through the use of passive components for power conditioning, galvanic isolation and regulation, delivering redundant fieldbus power up to 28V, 500mA per segment.

Benefits of the 9180 redundant fieldbus power supply range:

• Eight segment power supplies with flexible N+1 redundancy

• Fully isolated design

• Hot-swappable power modules

• Low power dissipation

• Choice of rising cage clamp screw or spring clamp terminals

• Screen passthrough or ground option without additional accessories

• Optional on-line diagnostics

• Optional pluggable trunk surge protection

• Support for Ex ic spurs when used with the F300 Megablock range and F30 Ex ic adaptor

MTL F800 Range – High Density Fieldbus Power Supplies

The MTL F800 range is an eight-segment, high-density fieldbus power supply system. Module carriers provide terminations for eight fieldbus segments and allow mounting of two F801 or F802 power supply modules.

The F801 power supply modules provide eight outputs rated at 21.5V, 350mA. The F802 power supply modules provide eight outputs rated at 28V, 500mA, making them suitable for applications with fieldbus trunk lengths greater than 600m or heavily loaded fieldbus barrier installations.

Both options ensure that one fieldbus terminator is included for each segment. The F800 carriers themselves contain no electronic components, maximizing MTBF and overall system availability.

Benefits of the F800 redundant fieldbus power supply range:

• Eight segment power supplies with 1+1 redundancy

• Low power dissipation

• Choice of rising cage clamp screw or spring clamp terminals

• Optional on-line diagnostics

• Horizontal or vertical DIN-rail mounting

MTL FPS Range – Legacy Fieldbus Power Conditioners

The legacy MTL FPS range provides redundant fieldbus power for a single fieldbus segment and is available with or without an integrated terminator.

Key features of the FPS range:

• High power output

• Two levels of power redundancy

• Component failure alarm

• Integrated fieldbus terminator

• Simplified power wiring

About Eaton MTL Instruments

Eaton MTL Instruments, a division of Eaton Corporation (USA), is a global leader in surge protection solutions for signal, data and power applications. With over 50 years of experience, MTL products are engineered to perform reliably in harsh and hazardous environments.
